Model No: 1103041
DONJOY Stainless steel mixing proof butterfly valve with pull handle
Delivery :
FOB
minimum order :
10 pieces
Supply Ability :
1000pieces / Month
Country of Origin :
NINGBO OR SHANGHAI
Quantity :
USD194.00 - USD230.00
/ pieces
- Type:Butterfly Valves
- Place of Origin:CN;ZHE
- Temperature of Media:Normal Temperature
- Power:Manual
- Media:Water
- Structure:Butterfly
- Brand Name:DONJOY
- Model Number:1103041
- Port Size:DN10-DN300, 1/2"-12"
DONJOY Stainless steel mixing proof butterfly valve with pull handle
Max.working pressure | 10Bar |
Max.Working Temperature | 130 degree C |
Valve Body Material | SS304/SS316L |
Seal Material | EPDM (standard) FPM/SILICON/NBR, FDA177.2600 |
Availably size | 2"-4", DN50-DN100 |
Availably connection | Clamp / weld / thread/ weld thread/ flange |
Availably standard | 3A/DIN/SMS/RJT/ISO/IDF |
Operated | Manual,Pneumatic, Electric |
Control | Sensor, C-TOP, C-top controller(AS-I) |
Handle option | pull handle, plastic/SS multi-positon handle |
Handle application | Two-position handle, three-position handle, four-position pull handle, multi-position plastic handle and multi-position stainless steel handle |
Actuator application | Stainless steel actuator/ Horizontal pneumatic actuator |
Certificate | ISO, PED/97/23/EC, FDA.177.2600 |
